Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 121
Fig. 243. The construction of the views is so obvious thatno explanation need be offered with the drawingshown in Fig. 244. It will be noticed that thisfigure, as well as all others in this chapter, areshown with lines representing the sides of the dif-ferent parts of the object. Draw two… … Fig. ;244. It is evident that a hexagonal prism has six facesand of these three are parallel to the remainingthree faces. The distance between any two parallelfaces or sides is the same ; in this case it is equalto 23^; let us draw the top view of the prism firstof all. ROGERS DRAWING AND DESIGN.…
Mechanical drawing · Machine design
