Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 148
Fig. 146. Type Problem. Perspective of Brace PREPARATORY INSTRUCTIONS FOR DRAWING PLATE 14 In this plate the student will need to decide for himself thenumber of views necessary, and their arrangement, to show theform of the object. It is suggested that for this purpose hereview the principles… … B DETAILBRACE JOINT !■- I^-I SCALE-FULL SIZE Fig. 147. Type Problem. Detail of Brace Joint
Mechanical drawing
