Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 129
ameter^ isplaced another pipe 8long, j outside diameterand 2 inside diameter. Draw the top view andsection of these twopipes. The top view(Fig. 257) shows three cir-cles, 4, 3 and 2 in diam-eter ; the section on theline AB shows one-halfof one pipe within the halfof the other pipe. Thesection lines… … Fig. 258. Fig. 258 shows the plan and section of such a ring.The drawing does not require any special explanation. ROGERS DRAWING AND DESIGN. Draw two views of the cylinder with square Jlangeshown in Fig. 2^g. Let the side of the cylinder be lo long (entireleno-th) outside diameter 4, inside…
Mechanical drawing · Machine design
