Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)

Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 156

An illustration from Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc, 1913, leaf 156
Fiu. 285. ROGERS DRAWING AND DESIGN. 171 cessively equal to the lines st, ku, Iv, mw, nx, oy,and pz ; in this manner one-half, ADEB of thedesired development of the smaller cylinder is the rectangle VWUT, VU being equal to the lengthof the cylinder and VW to its circumference. It maybe divided into…

Mechanical drawing · Machine design

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
