Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 162
FlO. 21)2. Fig. 293. line N2 lay off the distance JR equal to 2X. Fromthe point K. on the line O i lay off the distance KSequal to Vi and from the point L on the line PFlay off the distance LT equal to UW ; through thepoints thus obtained draw the curve HORST. Itis now possible to draw the…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
