ed in a direction opposite tothe motion of the hands of a clock. Such a thread isshown in Figs. 336 and 337. Screws maybe eithersingle-threaded or double-threaded. If we assumethat a screw consists of a cylinder with a coil form-ing the thread wound around it, we may easily definea double screw as…
