Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 222
center line,describe a circle cutting the center line at the pointsB and C. Set the compasses to the distance BCand from the point B as center, describe an arc cut-ting the outline of the upper plate in the point D.Make BE equal to the distance AD and with E as ROGERS DRAWING AND DESIGN. 245 center… … The length of the rivet required to form the headis about i^ times the diameter of the rivet. Forcountersunk rivet heads, a trifle more than one-halfof this amount is allowed. Riveted joints may give way because of the tear-ing of the plates between the rivets, as illustrated inFig. 364, by…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
