Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 227
each plate is pierced by a doublerow of rivets. When the rivets are opposite eachother, as in Fig. 372, the seam is known as chain-riveted. When the positions of the rivets in one row areopposite the spaces between the rivets in the otherrow, the seam is staggered. The following illustrations are… … Fig. 381. ,~^ A similar joint for S/i plates is also shown in Fig.376. Here the pitch is 2^ and the rivets ir, theholes being made i. Another joint of the same T
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
