Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 253
rim of the other wheel ; a rotation ofthis kind is called a positive rotation. Both wheelswhen in positive rotation by rolling contact, will have the same ratio of velocity, or as it is generallytermed a constant velocity ratio. The number of revohitions of the shafts will beinversely proportional… … Fig. 424. secure this condition, the wheels are provided withteeth which will enable them to rotate without thepossibility of slipping. To avoid a separate velocity for each tooth andto obtain an equal speed velocity in all parts of thewheel, the teeth are designed with proper proportions,which…
Mechanical drawing · Machine design
