Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 87
Fig. 137. One Part Piston. Fig. 138. Piston and Follower. made with eccentric diameters Fig. 139 with the cut on the thin side.The cut may be diagonal or lap, as in the figure. … / I Fic. 139. Piscon Rings.
Machinery
