Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 290
t 3ji i … Fio. 474. Fig. 472. Fig. 473. 318 ROGERS DRAWING AND DESIGN. the adjustment of the work, which is fed either auto-matically or by hand feed, while the rotating cutterremoves the superfluous metal. In illustrations Nos. 475 and 476 are illustratedan approved form of a vertical spindle…
Mechanical drawing · Machine design
