300. DIRECT-ACTING CENTRIFUGALGOVERNOR.—The balls traverse the radialarms a, a, on friction rollers and are restrainedby steel ribbons that pass over a pair of pul-leys at G, and are attached to the spring and ] g grooved collar that operates the lever and ^ throttle valve. … 301. SPRING BALANCED CENTRIF-UGAL GOVERNOR, Proell patent—Theballs are attached to the inverted arms d, b^ andraise the collar sleeve by their outward throw.The movement is restrained by the vertical leafsprings and links. The lift is controlled by thecurved links hung from the cross bar 2Xf, STEAM…
