rmediate stud gear must have5 X 16^80 teeth; the second intermedi-ate stud gear could have 16 teeth and thelead screw gear 80 teeth. Or 15 and 75could be taken for the first pair and 16 and80 for the second pair, or in fact any pair ofgears having the desired velocity ratio. Figure 488 represents a…
