he extra, thickness adds strengthto the rim, the extra weight increases the centrifugalforce. Two or more cylinders are often used in one steamengine ; when two cylinders are used, they are usuallyarranged so that the two cranks of the separatecylinders are at an angle of 90° to each other.… … Fig. 527.
