Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 272
ttle to one side of the joint. The method of setting the hinge (Fig. 269) is given in the directions for making a screen. The loose-pin door butt (Fig. 270) is set in the same manner as Fig. 267. Locks. The variety of locks is so great that it is scarcely possi^ble even to\ classify them.The… … Ir^ 266 ELEMENTARY CABINETWORK bolt and spnng, and a place on the edge of the doorto bring the lock flush with the surface of the edgeof the stile. The common mistake is that noallowance is made in locating the hole for lettingthis plate, called the selvedge, into the wood, andthe hole is,…
Cabinetwork
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
