s Hawkins Indica-tor Catechism, and the student who desires to takeup the field of steam engineering, is respectfullyreferred to this work. 376 ROGERS DRAWING AND DESIGN. Fig. 544 shows a valve diagram, as well as atheoretical form of an indicator diagram. The ra-dius of the eccentric equal to… … Fig. 540. inside lap is equal in length to Og, the width ofthe steam port is given by MK, which is equal togh. When the steam is admitted, the crank is inthe position indicated by the line 06;. When thesteam is cut off the position of the crank is 06,.When the steam is released the crank is in the…
