Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 555
Ftg. 393.—Diagrams illustrating the Lap and Lead V of a Steam Cylinder Slide Valve.In both sections, S and S are the steam ports, and D the exhaust. The upper sectionillustrates the laps of a valve; the space between the lines C and X giving the outside lap, and between the lines X and I the inside…
Automobiles
