s on the outside of the valves are operatedby a number of links, and in this manner the motionof the valves is actuated. The Corliss valve gear is used in a large numberof steam engines. Fig. 551 shows a side elevationof the valve gear, while Fig. 552 exhibits a partiallongitudinal section of the…
