Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 59
r planedguides. Both top and bottom rubbing surfaces or shoesare adjustable and have babbitt metal inserted in grooves or 44 STEAM ENGINES holes to reduce friction. With this type of crosshead the guidesare not adjustable but the shoes of the crosshead are adjustedto take up wear and to bring the…
Steam-engines
