Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 360
Figs. 556, 557 and 558. 390 ROGERS DRAWING AND DESIGN. The disc seen in the middle of the cylinder inFig. 551, called the wrist plate, is made to rock uponthe stud in its center by a rod leading from theeccentric on the crank shaft. The wrist plate hasfour valve connecting rods, which connect it…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
