Rudimentary treatise on the erection of dwelling-houses : illustrated by a perspective view, plans, elevations, and sections of a pair of semi-detached villas with the specification, quantities, and estimates and every requisite detail, in sequence, for their construction and finishing / by S.H. Brooks. (1874)

Brooks, S. H. (Samuel H.) · London : Lockwood · leaf 216

An illustration from Rudimentary treatise on the erection of dwelling-houses : illustrated by a perspective view, plans, elevations, and sections of a pair of semi-detached villas with the specification, quantities, and estimates and every requisite detail, in sequence, for their construction and finishing / by S.H. Brooks., 1874, leaf 216
Plate XVII. DETAILS OF BRICKWORK FOR CHIMNIES 4—r … Plate XVIIr. FIG. II. SECTION I T END TRIMMER A STONt A .. STONEFOR SU PPORTI N C BJ^rCK WALL Or END TRIMMERS END TRIMMER \ \ L__ C O R Q E L END TRIMMERS

Building · Architecture, Domestic

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
