The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 104

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 104
tages, no other deviation from theNorman than that of the arches being pointed ; but thesewere frequently introduced in situations where the old formwas actually built with and even surmounting them. Thuswe find them in the choir of the church of St. Cross Hamp-shire : the lower arches here are… … OF ARCHITECTURE. 97 centuries afterwards. In the transept of Koinsey church, atthe west end of Croyland abbey church, Lincolnshire, andin many other instances, the pointed arch is placed beneaththe serni-circular ; and this has not been an after alteration,but is really the original work. The span…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
