An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 235 — Rectangular Vaulting-pyramida a a a, groin, ribs.b b •, formerets.c c, tiercerons This improvement, not yet develop-ed fully, is shown in these engrav-ings, the first of which is a view ofthe porch of St. Sepulchre Xew-atgate, and the next of a porch atGuildhall. In the above example (St.… … Hexagonal Vaulting-pyramid,imperfect.y developed.Si. Sepulchre, Newgate OF ARCHITECTURE. 221
