The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 236

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 236 — Hexagonal Vaulting-pyramid,imperfect.y developed.Si. Sepulchre, Newgate OF ARCHITECTURE. 221 … this space would be larger inthe more perfect developmentof this method. Hence on alarge scale it is necessary thatthe space should be domed,and this is most consistentlydone by simply continuing theribs with unaltered curvature,till they meet and form two . , ,, , ,, Vaulting-conoid, with all its…
