The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 256

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 256
the most Temple church offers a rude approach, viz., a dodecagon with its covering support-ed by six pillars and eighteen arches, all of equal span, dividing the whole into acentral hexagon, surrounded by six square and six triangular compartments, allequilateral, and making the thirty lines… … OF ARCHITECTURE. 241 pure and consistent. It is not confined to England, butnearly so ; its only continental localities being Brittany andthe western part of Normandy. All provinces further eastexhibit various kinds of Early Pointed, different from ours ;and some of which were formerly supposed to…

Architecture · Building
