The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 298

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 298
of the soffit or underside of the abacus which overhang the echinuse e e e ; and s s the soffit of the architrave. From this, the rela-tion between the abacus and architrave, and how much the formerexceeds or projects out beyond the latter, will be better understoodthan by the engraving Fig. 1 p.…
