The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 303

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 303 — 2S4 GLOSSARY. irw/nr, Cable-moulding. … Canopy. Cyma Recta.—A compound moulding, hollow in ^ the upper, round in the lower part. Cyma Kecta Cyma Reyersa.—A moulding, the reverse of the cyma recta. Cymatium.—The upper moulding of an entablature. Cable-moulding.—A moulding used in Nor-man architecture, and deriving its name from itsform.…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
