The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 308

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 308 — Monotriglyphic.—That mode of intercolumniation in theDoric Order, according to which there is only a single triglyphover each intercolumn. Module.—The semi-diameter of the column, or 30 minutes. Minute.—The sixtieth part of the diameter of the column, asa proportional measure. Minutes are written…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
