The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 311

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 311 — Quatrefoil. … LS GLOSSARY. 291 Steeple.—A tower rising above the roof of a church. Section.—A vertical plan of the interior of a building, showingit as it would appear upon an upright plane cutting through it. Soffit.—From the Italian soffitto, a ceiling ; the under surfaceof any projecting moulding or member.…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
