The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 334

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 334 — to a shacklepassing round the head of the pile, whilst the other passesthrough a cross-head, resting firmly on temporary supportsplaced on each side of the pile. 40. Cofferdams.—A cofferdam may be described as awater-tight wall, constructed round the site of any work, forthe purpose of laying dry… … • ART OF BUILDING. 315 filled with clay, and sunk in line round the space to be en-closed ; but in the majority of cases, the method is to drivetwo or more rows of close piling, and to fill up the space be-tween them with clay puddle. 41. Cofferdams are sometimes formed, in shallow water,with a…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
