The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 34

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 34 — her intermediate OF ARCHITECTURE. 29 ones which follow the course of its revolutions. Again, theeathetus, or eye of the volute, where the spiral or spirals ter-minate, admits of being made smaller or larger. It is,besides, sometimes flat, sometimes convex, and occasionallycarved as a rosette. All…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
