Fig. 62. … ner of securing the struts to the wall posts and to the beamwith tongues and wooden pins. 121. Fig. 63 exhibits a construction often to be met with,which, in general appearance, resembles a trussed king postroof but which is in reality very different, the tie beambeing a strong girder supporting…
