The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 384

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 384 — eather, and from the liability of the self-acting cock to getout of order. Fig. 68: shows the ordinary arrangements of a cistern fora dwelling-house. The common material for the cistern itselfis wood lined with sheet lead ; but slate cisterns have beenmuch used of late. Large cisterns or tanks for… … ART OF BUILDING. 361

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
