The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 83

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 83 — Castle Acre Priory At St. Jamess,Bristol, within theinterlacing mould-ings, there is a lancetwindow, the arch ofwhich is struck fromthe same centres, andfollows the inside lines. In the above instances referred to.the intersecting semicircular windows are not detached fromthe wall. In Christ…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
