struts ; and, by extending this principle ad infinitum, wemight construct a roof of any span, were it not that a prac-tical limit is imposed by the nature of the materials. Some-times roofs are constructed without king posts, the queenposts being kept apart by a straining piece. This construc-tion… … roof (now destroyed) of the cliurch of St. Paul, outside thewalls, at Rome. This truss is interesting from its early date,having been erected about 400 years ago ; the trusses are inpairs, a king post being keyed in between each pair to sup-port the tie beams in the centre. 112. Of late years iron…
