Rudiments of the art of building : represented in five sections [...] for the use of architects, builders, draghtsmen, machinists, engineers and mechanics (1853)
Bullock, John · New York : Stringer & Townsend · leaf 76
Fig. 62. … ner of securing the struts to the wall posts and to the beamwith tongues and wooden pins. 121. Fig. 63 exhibits a construction often to be met with,which, in general appearance, resembles a trussed king postroof, but which is in reality very dififerent, the tie beambeing a strong girder supporting…
Building
Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
![An illustration from Rudiments of the art of building : represented in five sections [...] for the use of architects, builders, draghtsmen, machinists, engineers and mechanics, 1853, leaf 76](https://img.insideoutlibrary.com/img/1024/ia-rudimentsofartof00bull-76-46.webp)
