Sanitary arrangements for dwellings : intended for the use of officers of health, architects, builders, and householders (1874)

Eassie, William, 1832-1888 · London : Smith, Elder & Co. · leaf 30

An illustration from Sanitary arrangements for dwellings : intended for the use of officers of health, architects, builders, and householders, 1874, leaf 30
Bedding of Dram-pipes. 21 used in flushing the drain-pipes above. The otherpipe, which is drawn at fig. 22, is the only method ex-tant for carrying sewage through water or across ariver, and shutting out such sewage from the purer 21 22

Heating · Water-supply · Ventilation · Lighting · Plumbing · Domestic engineering · Sanitary Engineering
