Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)

Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 165

An illustration from Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics, 1895, leaf 165
Fig. 272. meets EA produced at M. From M draw a line parallel to ACtill it meets EC produced at P. Join PO. Then MOP will tethe similar triangle required. … Fig. 273. join GH, HK, KL, and LG.required. Pkoblem 170. To construct ivitliin a given squareABCD, and equidistant fromit, a square, one side of whichis equal to the given line E. Draw the diagonals AD andCB. From A on AB set off AFequal to the given line E. FromF, parallel to AD, draw a line…

Geometrical drawing

Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
