le ABC, and equidistant from its sides, a similar triangle, the base of which is equal to a given line L. Fig. 202. Set off on the base AB produced, AN equal to the given line L. From N draw a line parallel to EA (Prob. 3) till it meets EB produced at O. From O draw a line parallel to AB till it… … 150. from its sides, a square, oneside of which is equal to thegiven line E. Draw the diagonals AD andCB. From A set off AF alongAB equal to the given line E.From F, parallel to AD, draw aline till it meets CB at G (Prob.3). With M as centre, andradius MG, set off the points H,K, and L, and join…
