his called the foU: Erom C, along AB, set off any number of points at pleasure,1, 2, 3, etc., and draw lines from P through these points. Pro-duce the perpendicular OF below C, and select the point D.CD is called the diameter. - Set off along the lines radiating from P distances equal toCD, as IH,… … these points, it would be called the superior conchoid. If wetake the diameter greater than the length CP, the curve wouldhave a loop. CYCLOIDAL CURVES, ETC. 185 Pkoblem 206.To draw a, cissoid.The cissoid was invented by Diodes in the second century.
