132 FEEE-HAND GEOMETRICAL DRAWING. measured on lines drawn from a, fixed point. When this pointis nearer the fixed line than the fixed distance, one branch of … 4 Fig. 38. the curve will be looped. Thus E E is the fixed line, and Athe fixed point. Then dQ =: de ,• ha^hc, etc. GEOMETRIC SYMBOLISM. 133 106. Turning now from these curves to a complex educa-tional estal>lishment, we find for its corresponding fixed ele-ments, 1°, a foundation ootcrse of…
