Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)
Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 227
solids, viz. a cube, a rectangularsolid, a pyramid, and a triangular prism, and show the differentpositions they can occupy with reference to the co-ordinateplanes, i.e. the V.P. and H.P. Fig. 5 represents the four solids in what is called si^nplepositio7is, i.e. parallel to hoth the V.P. and H.P.… … Fig. 6. Fig. 6 represents the same solids with their bases on the H.P.as before, but their sides are now inclined, to the V.P. XVII INTRODUCTION 207 Fig. 7 shows them with their fronts and backs parallel to theV.P., as in Fig. 5, but with their bases inclined to the H.P,
Geometrical drawing
