Fig. 111. 46 PRACTICAL PLANE GEOMETRY Peoblem 54. … To inscribe a square in a giventriangle ABC. From C draw CD perpen-dicular to AB, and CE perpen-dicular to CD, and equal to it.Draw the line EB cutting ACin F. Draw FG- parallel toAB. Draw the lines FH andGL perpendicular to AB. ThenFGLH is the square required. Problem 55. In a given triangle ABC,…
