Fig. 153. TANGENTS AND TANGENTIAL ARCS 65 Problem 90. To draw a circle which shall pass through the given poi7it Aand touch a given line BC in D. At the given point D erect the line DE perpendicular to … BC (Prob, 5), and join AD. At point A construct an angleDAE equal to the angle ADE (Prob. 12). AE intersects DE inE. With E as centre, and ED as radius, draw the required circle. Peoblem 91. To draw a circle which shall joass through the two givenpoints A and B and touch the given line CD. Join the…
