D Fig. 169. Problem 105. To inscribe in a segment of acircle,, lohose centre is E, tivogiven equcd circles with aradius equal to line D. Prom any radius EP cutoff PL = D, and describe acircle with radius EL. Drawthe line KL parallel to thebase of the segment, and at adistance equal to given radius… … Problem 106. In the given sector of a circleABC, to inscribe a circletangential to it. Bisect the angle ACB by theline I) (Prob. 13). At D drawa tangent HL (Prob. 84) to meetthe sides of the sector produced.Bisect the angle CLH by a linecutting CD in E. With E ascentre, and ED as radius, drawthe…
