Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 104

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 104
portion of the dome in its finished state. The construction of this dome is extremely simple, and the appearancewhen finished would be light and elegant. It is proposed to glaze everyalternate space between the bars. The circular rods which receive thecircumference of the dome are fixed to the ribs…

Public buildings · Architecture

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
