Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 168

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 168
ff. 5 is the plan of tlie top of the box, which should be kept downin the water to the rim l)y a regulated pressure weight. Fig. 6 is a perspective sketch of a portion of one of the retorts, showingthe method of attaching the mouth-piece and fastening the door. Fig. 7 is a sketch of the furnace… … >v„
