Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 266

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 266
s mode of connecting the suspension rods, the contrac-tion and expansion of the rods are provided for. Fig. 8. This is a section of the clips attached to the vertical rods, andsecure the iron bearers a a, which run the whole length of the bridge, andsupport the roadway. Fig. 9. Is the elevation of… … : < 1 1 i h ^L H° 1

Public buildings · Architecture
