Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 274

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 274
shed state, Avith thegutters, parapets, buttresses, and lantern light. Fig. 2. Is a half-plan showing the timbers of the roof, and the metalbearers which support the lantern light. Fig. 3. Is a hall-phin of the lantern light in a finished state. Fig. 4. Is a half-plan of the same showing the…

Public buildings · Architecture
