Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 284

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 284
floor. Fig. 7. Is a longitudinal section of the same. Fig. 8. Is a section of the foundation and footings. Fig. 9. An elevation of the same. Fig. 10. Shows the mode of constructing the floor of the central building. Fig. 11. Is the same, with the joists. Fig. 12. Shows the mode of fixing the… … 4 -ate: ... \ f

Public buildings · Architecture

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
